Polycrystalline Solar Panel

Polycrystalline Solar Panel

Anern series modules consist of poly-crystalline high-efficiency silicon cells that are individually characterized and electronically matched before interconnection and laminated with toughened glass, EVA and Backsheet of high quality. Adopt most advanced PERC cells technology, high conversion rate.

After assembled with anodized aluminum alloy frame, cable and junction box with MC4 connectors, Anern solar modules can be installed easily and work for a long period. They can also withstand the storm, strong wind and hail impact,etc. More than 25 years lifespan.

Send Inquiry

Polycrystalline Solar Panels Parameter

Model

320W

330W

340W

350W

Maximum Power Voltage (Vmp)

37.50V

38.20V

38.50V

38.90V

Maximum Power Current (Imp)

8.53A

8.64A

8.83A

9.00A

Open Circuit Voltage (Voc)

45.00V

45.84V

46.20V

46.68V

Short Circuit Current (Isc)

8.96A

9.07A

9.27A

9.45A

Max System Open Circuit Voltage

1500V

Junction Box(Protection Degree)

≥IP67

Operate Temperature Scope

-40~+85℃

Frame Thinkness

40/45mm

Dimensions(L x W x H)

1956*992*40mm/1980*1002*40mm

Weight

20.3kg


Polycrystalline Solar Panels Advantages

Polycrystalline Solar Panels Advantages

Polycrystalline Solar Panels Advantages
Reliable Quality
  • High PID resistance.

  • Self-cleaning function.

  • Service life up to 25 years (30 years optional).

  • Through advanced battery technology and manufacturing capabilities.


Polycrystalline Solar Panels Advantages
22% Conversion Efficiency Of Solar Panels
  • Module efficiency up to 22%.

  • Configure the solar cells in module and adopt advanced battery technology.

Polycrystalline Solar Panels Advantages
Frame Optional
  • Silver or black frames are optional.

  • Serrated-clip design tensile strength.

  • Seal-lip design glue injection.

Polycrystalline Solar Panels Advantages
Junction Box
  • Excellent heat dissipation performance.

  • High quality diode ensures module running safety.

  • Conventional standalone edition and engineering custom edition.

ANERN Polycrystalline Solar Panels Factory

Anern possesses a professional automation polycrystalline solar panel factory. We have equipped advanced automated production equipment. We have obtained the certification of ISO9001, CE, ROHS, TUV, etc, which is enough to prove that Anern can provide customers with high-quality polycrystalline solar panels for sale. And our experienced engineers will provide customers with their favourite solar products solutions.

  • anern polycrystalline solar panels factory 1
  • anern polycrystalline solar panels factory 2
  • anern polycrystalline solar panels factory 3
  • anern polycrystalline solar panels factory 4
  • anern polycrystalline solar panels factory 5
  • anern polycrystalline solar panels factory 6
anern polycrystalline solar panels factory 1
anern polycrystalline solar panels factory 2
anern polycrystalline solar panels factory 3
anern polycrystalline solar panels factory 4
anern polycrystalline solar panels factory 5
anern polycrystalline solar panels factory 6
Get in Touch with ANERN
Professional service

Focus on providing customers with one-to-one services, and one-stop solar system solutions.

Patented design products

Anern has set up a professional R&D team, 70% of the products are exclusively designed.

Worldwide partners

Anern has cooperated with customers in more than 200+ countries regions around the world, and is a reliable supplier for customers.

Factory Outlet

Anern factory covers an area of more than 30,000 square meters, and the supply capacity can fully meet any needs of customers.
